Scanner Flatbed Parts
Collar
382
PA03002-C214FJ Carrier tension pulley collar - Sleeve that carrier pulley tension spring slides over
Cover
383
PA03002-C104FJ Flatbed cover assembly - With paper chuter flip out and document holding pad
384
PA03002-C256FJ Carrier unit dust cover
Cover Pad
385
PA03002-C267FJ Junction PCA cover - Protects junction PCA
386
PA03002-C270FJ Front panel cable cover - Protects front panel cable
Extension
387
PA03002-C260FJ Paper chute flip out - Flip out paper tray extension
Ferrite Assembly
388
PA03002-C262FJ Ferrite core - Attaches to the carrier ribbon cable
Foot
389
PA03002-C218FJ Rubber foot
Glass Assembly
390
PA03002-C219FJ Glass plate assembly - Copier flatbed glass, frame and lower ADF exit roller assembly
Lamp
391
PA03002-C114FJ Lower lamp - Front side of carrier unit
Motor
392
PA03002-C116FJ Carrier unit motor
Pad
393
PA03002-C105FJ Document holding pad - Foam piece on bottom of flatbed cover that holds document to copier glass
Pulley
394
PA03002-C210FJ Carrier tension pulley - Carrier belt idler pulley
Rail
395
PA03002-C205FJ Carrier rail - Carrier unit front support rail
Sensor
396
PA03002-C207FJ Home postion sensor - Senses when carrier unit is parked in the home position
Shaft
397
PA03002-C211FJ Carrier tension pulley shaft - Axle for carrier belt tension pulley
Spacer
398
PA03002-C213FJ Carrier tension pulley spacer
Spring
399
PA03002-C208FJ Frame ground spring
400
PA03002-C209FJ Idle roller coil spring - Provides tension for idle roller
401
PA03002-C212FJ Carrier spring - Provides tension for carrier belt pulley
Stop
402
PA03002-C226FJ Document cover rubber stop
Tool
403
PA03002-C259FJ Lubrication applicator - Carrier unit rail lubricator
Scanner Internal Parts
Bracket
404
PA03002-C222FJ Output tray bracket - Rear ADF output tray mount
405
PA03002-C223FJ Output tray bracket - Front ADF output tray mount
