LaserJet 8150HN
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Other Internal Parts
Spring
339
RS5-2499-000CN Tension spring - Front spring on metal slide
Stop
340
RB1-6427-000CN CG stopper - Toner cartridge guide stop - Holds toner cartridge in place
341
RB1-6783-000CN Tray stop - Right side tray stopper - Attached to right rear side of Tray 2 and 3 - Blue plastic piece
Paper Path Parts
Arm
342
RB1-6557-000CN Paper input unit sensor arm - Senses when paper passes through paper input unit
Bushing
343
RB1-6441-000CN Transfer guide bushing
Clutch
RG5-4308-000CN Registration assembly clutch
345
RH7-5188-000CN Paper feed clutch
RH7-5204-000CN New Part for RH7-5188-000CN
Cover
346
RB2-3631-000CN Paper feed clutch cover
Delivery
347
RG5-1874-110CN Face down delivery assembly - Feeds paper to top of printer
Diverter
348
RG5-4325-000CN Diverter assembly - Diverts paper to duplexer assembly or face up tray or face down delivery assembly
Drive Assembly
349
RF9-1249-000CN Diverter drive assembly - 4 gear drive assembly - 20 tooth gear NOT included
350
RG5-4365-000CN Main drive gear assembly
Feed Assembly
351
RG5-4305-000CN Feeder assembly - Transfer roller and registration assembly are mounted on this assembly
Guide
RF5-1394-000CN Transfer guide - Guide transfer roller is mounted into
353
RF5-2676-000CN Transfer guide
Holder
354
RB1-6461-000CN Damper holder - Front damper holder
355
RB1-6462-000CN Damper holder - Rear damper holder
Kit
C3914-67902 Maintenance kit (120V) - Replacement parts after 350K pages includes, fusing assembly, eight feed/separation rollers,
and transfer roller - NOTE: Pickup rollers are not included in this kit - Please order separately if needed
C3914-69001 Maintenance kit (120V) - Replacement parts after 350K pages includes, fusing assembly, eight feed/separation rollers,
and transfer roller - NOTE: Pickup rollers are not included in this kit - Please order separately if needed
REQUIRES RETURN OF DEFECTIVE PART
C3914-67902 New Part for C3914-69001
C3915-67902 Maintenance kit (220V) - Replacement parts after 350K pages includes, fusing assembly, eight feed/separation rollers,
and transfer roller - NOTE: Pickup rollers are not included in this kit - Please order separately if needed
C3915-69001 Maintenance kit (220V) - Replacement parts after 350K pages includes, fusing assembly, eight feed/separation rollers,
and transfer roller - NOTE: Pickup rollers are not included in this kit - Please order separately if needed
REQUIRES RETURN OF DEFECTIVE PART
C3915-67902 New Part for C3915-69001
