LaserJet 8150HN
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Mailbox Components
Stapling Unit
266
C4787-69513 Stapling unit - Includes top cover, bed assembly, and board
REQUIRES RETURN OF DEFECTIVE PART
C4787-60513 New Part for C4787-69513
Tape
267
C4785-60507 Metallic tape and housing assembly - Narrow tape version used with the double belt transport belt system
268
C4785-60524 Metallic tape and housing assembly - Wide tape version used with the single belt transport belt system
Optional Interfaces
Interface (Product)
J3110A Ethernet 10Base-T (RJ-45) EIO network internal print server PC board
J3111A Ethernet 10Base-T/10Base2 and LocalTalk (RJ-45, BNC, LocalTalk) EIO network PCA
J3112A JetDirect 600N token ring LAN interface board - DB-9 and RJ-45 connectors
NO LONGER SUPPLIED
J3113A JetDirect 600N internal print server (10Base-T and 100Base-TX) LAN interface board - Plugs into peripheral EIO slot
J4135A JetDirect connectivity card - Has one USB port, one serial (DB9) port and one LocalTalk port - Plugs in the EIO slot on
selected DesignJet and LaserJet printers
J4167A JetDirect 610N token ring LAN interface board - DB-9 and RJ-45 connectors
J4169A JetDirect 610N internal print server (10Base-T and 100Base-TX) LAN interface board - Plugs into peripheral EIO slot -
Has a RJ-45 connector - Comes with software on CD-ROM and manual
PC Board (Interface)
J3112-69001 JetDirect 600N EIO internal print server token ring LAN interface board - Has one RJ-45 and DB-9 connector
J4167-69001 New Part for J3112-69001
J3113-69001 JetDirect 600N EIO internal print server 10Base-T and 100Base-T LAN interface board - Has one RJ-45 connector
J4135-61001 JetDirect connectivity card - Has one USB port, one serial (DB9) port and one LocalTalk port
Optional Paper Trays
Envelope Feeder
C3765-69501 Replacement optional envelope feeder - Holds 100 envelopes
REQUIRES RETURN OF DEFECTIVE PART
C3765-60501 New Part for C3765-69501
C3765B Optional envelope feeder - Automatically feeds 100 envelopes
Guide
RF5-1484-000CN Paper size guide/stop - For upper or lower paper input tray
Mailbox
282
C4787A 5-bin mail box with stapler - Holds 2100 sheets of paper used with 5Si family, mopier and 8000 printers
Stop
RF5-2002-030CN Paper length stop
Tray
C4780A HP LaserJet 8000 and 8100 Series Optional 1000 (2 x 500) sheet paper trays (Trays 4 & 5) - Holds up to 1000 sheets of
letter, legal, tabloid/ledger, A3, A4, B, or B4 size paper - Does NOT include paper handling PCA
285
C4781A HP LaserJet 8000, 8100, and 5Si Series Optional 2000 sheet paper tray (Tray 4) - Holds up to 2000 sheets of letter,
legal, tabloid/ledger, A3, A4, B, or B4 size paper - Does NOT include paper handling controller board
C4785A 8 bin mail box - Holds 2600 sheets of paper - Used with 2000 sheet paper tray or printer cabinet
R98-1004-000CN Lower paper input tray (Tray 3) - 500 sheet capacity - For letter, legal, 11 x 17 inch (B-size), A4 (210MM x 297MM), A3
(297MM x 420MM) and B4 (257MM x 364MM) size paper
R98-1005-000CN Upper input paper tray (Tray 2) - 500 sheet capacity - For letter, legal, and A4 (210MM x 297MM) size paper
© 2004 Hewlett-Packard 12
