HP J4100A 10/100Base-TX Print Server B-1
B
J4100A
10/100Base-TX
B
HP J4100A 10/100Base-TX Print Server
Supported Links
HP J4100A JetDirect 10/100 Base-TX print servers support 10 or
100 Mbps operation in full- or half-duplex modes. In most cases,
full-duplex is supported when the connecting network device—
such as a network switch or hub—supports IEEE 802.3u
autonegotiation specifications.
When connecting to network devices that do not support
auto-negotiation, or that implement non-conforming link
negotiation, the print server will configure itself for
10-
or
100-Mbps half-duplex
operation. For example, when connected
to a non-negotiating 10-Mbps hub, the print server card will
be automatically set to operate at
10-Mbps half-duplex
.
If the card is not able to connect to the network through
autonegotiation, you can manually set the link operating
mode using
link configuration jumpers
on the card.
Link-Speed LEDs
The HP J4100A print server provides 2 light-emitting diodes
(LEDs) near the RJ-45 connector. These LEDs indicate the
operating link speed of the print server, either 10 or 100 Mbps.
LED State: Off On
Description: Not linked Link established at the
indicated speed (Mbps)
100 Mbps LED
10 Mbps LED
