Control Panel for Large-Format Printers 4-7
4
HP DesignJet
Control Panel
To configure a NetWare frame type
If you haven't already done so, enable Novell NetWare by following
the instructions described in “To enable or disable network
protocols” in this chapter.
For the 600 Series Printers
1. Access the configuration menu (see “To enable or disable
network protocols” in this chapter).
2. Press
↑
until
Novell→
or
Auto→
appears.
3. Press
↑
.
MIO SETUP
and
FRAME=<current frame type>→
appear.
4. To maintain the current frame type, press
↑
.
5. To change frame type, proceed as follows:
a. Press
[Enter]
to display the current frame type.
b. Press
↑
until the frame type you want appears.
c. Press
[Enter]
to save the new frame type.
For the 700/2000/2500/3000/3500 Series Printers
1. Access the configuration menu (see “To enable or disable
network protocols” in this chapter).
2. From the
CFG IPX/SPX=NO→
menu item, press
[Enter]
,
↓
,
[Enter]
to display
CFG IPX/SPX=YES→
.
3. Press
↑
to display
FRAME=AUTO.
4. To change the frame type, press
[Enter]
and
↓
until the frame
type you want is displayed. Press
[Enter]
to select the frame type.
5. Press
[Previous]
and return to
STATUS Ready
.
6. To save the configuration, print a configuration plot by pressing
the two arrow keys simultaneously. Your printer configuration
is now active.
To manually configure other parameters, see the appropriate
sections in this chapter.
To complete the print server configuration, see the HP JetDirect
software installation guide included with the product.
