10Ć8 Parts and Diagrams
C4699Ć90000
End Covers
Reference
HP Part Number
Quantity Description
on
Drawing
DesignJet
330/350C
DesignJet
230/250C
1 C4699Ć40004 C4699Ć40004 1 Left EndĆCover
2 C4699Ć00008 - 1 Nameplate (DesignJet 350C)
C4701Ć00008 - 1 Nameplate (DesignJet 330)
- C3190Ć00022 1 Nameplate (DesignJet 250C)
- C4694Ć00001 1 Nameplate (DesignJet 230)
3 C4699Ć00007 C4699Ć00007 1 Instruction Label
4 C4699Ć40005 C3190Ć40016 1 Right EndĆCover
5 C3190Ć40029 C3190Ć40029 1 PinchĆArm Lever
6 C3190Ć40045 C3190Ć40045 1 Switch Button
7 C3190Ć60144 C3190Ć60144 1 Front Panel Assy
8 C4699Ć00009 C3190Ć00033 1 Media Label
9 5961Ć3524 5961Ć3508 1 Serial Label
10 0515Ć1349 0515Ć1349 1 Screw M3 x 30 Mach T10
11 0535Ć0031 0535Ć0031 1 Nut HGX M3 x 2.4
12 See page 10Ć27 See page 10Ć27 1 FrontĆPanel Overlay
13 C4701Ć40001 - 1
Cartridge Cover (DesignJet 330)
14 C3178Ć00030 C3178Ć00030 1 Carriage Label
(DesignJet 350C/250C)
C4701Ć00009 - 1
Carriage Label (DesignJet 330)
15 C3190Ć40052 C3190Ć40052 1 QRG Holder
