8Ć24 Troubleshooting
C4699Ć90000
Filename Failure
(and most frequent causes)
Line Number
Filename Failure
(and most frequent causes)
Firmware
A.01.00
testmode.c 3684 Error in DRAM data test:
D Faulty carriage.
testmode.c 3691 Error in DRAM addresses test:
D Faulty electronics module.
testmode.c 3698 Unknown DRAM error:
D Faulty electronics module.
testmode.c 3722 Error in the test of the inĆbuilt ROM and
ROM SIMM performed at powerĆon:
D ROM SIMM badly seated.
D Faulty ROM SIMM.
D Faulty electronics module.
testmode.c 3733 Error in the test of the masked ROM:
D Faulty electronics module.
main.c 238 Failure in cartridge initialization:
D Faulty or badly connected trailing cable.
main.c 381 Failure in fan connection test:
D Faulty electronics module.
main.c 230 or
354
Model ID configuration incorrect.
Reconfigure the plotter ' page 8Ć28.
selftest.c 1502 Failure in test to actuate inĆbuilt ROM or
ROM SIMM:
D ROM SIMM badly seated.
D Faulty ROM SIMM.
D Faulty electronics module.
selftest.c 1506 Failure in maskedĆROM test:
D Faulty electronics module.
selftest.c 1513 Failure in mainĆPCA DRAM test:
D Faulty electronics module.
