-20-
G0572 Hanging Air Filter with Remote
Figure 16. Remote Control.
To operate the air filter unit, use the listed
controls:
• OFF: Allows you to manually turn the air filter
OFF.
• ON / SPEED: Allows you to turn the unit ON
with the first push of the button, and for every
additional push, the fan speed is cycled
from LO, MID, and HI. Speed selection is
indicated by a red LED light.
To operate the remote control unit, use the
listed controls:
• OFF: Allows you to remotely shut the air filter
OFF.
• ON / SPEED: Allows you to remotely turn the
unit ON with the first push of the button, and
for every additional push, the fan speed is
cycled from
LO to MID and to HI.
• TIME: Allows you to set the auto shut-off
time from no auto shut-off, to auto shut-off in
1 hour, 2 hours, and 4 hours.
Remote Control
The remote control unit enables you to remotely
turn the air filter
ON and OFF, set the fan speed,
and set the auto shut-off time. The remote control
unit uses two AAA alkaline batteries as a power
source. The remote control unit
(see Figure 16)
must be within 75 feet of the filter unit and have
an unobstructed infrared signal path to the control
panel.
Accessories
Grizzly carries a complete selection of fine
accessories for all of its equipment. Below is a
list of replacement filtlers and accessories we
are sure you will find useful.
• Dust Collection Basics, Model G2525
• Remote Dust Collector Switch, Model
H2797 or H5397
• Primary Filter, P0572024
• Secondary Filter, P0572022
