Default Gateway Default gateway XXX.XXX.XXX.XXX
TCP/IPv6 TCP/IPv6 Enable/Disable
IP Address *2 IP address XXXX:XXXX:XXXX:XXXX
XXXX:XXXX:XXXX:XXXX
Subnet Prefix Length *2 Subnet prefix length XXX
Default Gateway *2 Default gateway XXXX:XXXX:XXXX:XXXX
XXXX:XXXX:XXXX:XXXX
IPsec *3 IPsec setting Active
Security Protocol *3 Security method ESP/ESP & AH/AH
Access Point Mode Access point mode Enable/Disable
Connection Connection status Active/Inactive
SSID SSID Access Point Mode SSID
Password Password Password of the access point mode (8 to 10
alphanumeric characters)
Channel Channel 3
Encryption Encryption method AES
Authentication Authentication method WPA2-PSK
TCP/IPv4 TCP/IPv4 Enable
IP Address IP address XXX.XXX.XXX.XXX
Subnet Mask Subnet mask XXX.XXX.XXX.XXX
Default Gateway Default gateway XXX.XXX.XXX.XXX
TCP/IPv6 TCP/IPv6 Enable/Disable
IP Address *2 IP address XXXX:XXXX:XXXX:XXXX
XXXX:XXXX:XXXX:XXXX
Subnet Prefix Length *2 Subnet prefix length XXX
Default Gateway *2 Default gateway XXXX:XXXX:XXXX:XXXX
XXXX:XXXX:XXXX:XXXX
IPsec *3 IPsec setting Active
Security Protocol *3 Security method –
Other Settings Other settings –
Printer Name Printer name Printer name (Up to 15 alphanumeric characters)
WSD Printing WSD printing setting Enable/Disable
WSD Timeout Timeout 1/5/10/15/20 [min]
240
