Contents
viii HSIM-F6 User’s Guide
3.9 The Full Duplex Configuration Screen .......................................3-23
3.9.1 Full Duplex FDDI...........................................................3-24
3.9.2 Full Duplex Configuration Screen Fields.......................3-25
3.9.3 Configuring the HSIM-F6 for Full Duplex Operation......3-26
3.10 The FDDI/Ethernet Translation Configuration Screen ...............3-27
3.10.1 FDDI Translation Configuration Screen Fields..............3-28
3.10.2 Setting Frame Translation Types ..................................3-30
3.10.3 Setting the Frame Translation Types
to the Default Values.....................................................3-31
3.10.4 When to Set the Interpret 802.3 Length
for Frames > 64 Bytes Field to [ENABLED] ..................3-31
3.10.5 Setting the Interpret 802.3 Length
Field to [ENABLED].......................................................3-31
CHAPTER 4 LANVIEW LEDs
4.1 HSIM-F6 LED State Definitions ...................................................4-3
CHAPTER 5 SPECIFICATIONS
5.1 Fiber Optic Interface ....................................................................5-1
5.1.1 Multimode Specifications.................................................5-1
5.1.2 Single Mode Specifications .............................................5-2
5.2 Unshielded Twisted Pair (UTP) Specifications ............................5-4
5.3 Shielded Twisted Pair (STP) Transmitter Specifications .............5-5
5.4 Cable Specifications ....................................................................5-6
5.4.1 Multimode Fiber Optic Cable Length...............................5-6
5.4.2 Single Mode Fiber Optic Cable Length ...........................5-6
5.4.3 Twisted Pair Cable Length ..............................................5-7
5.5 Twisted Pair Pinout Configuration................................................5-7
APPENDIX A FPIM SPECIFICATIONS
A.1 FPIM-00 and FPIM-01 ................................................................ A-1
A.2 FPIM-02 and FPIM-04 ................................................................ A-2
A.3 FPIM-05 and FPIM-07 ................................................................ A-3
