Clean-Up After Installation
In order to avoid dulling and scratching the surface of
the bath, never use abrasive cleaners. A mild liquid
detergent and warm water will clean soiled surfaces.
Remove spilled plaster with a wood or plastic edge.
Metal tools will scratch the surface. Spots left by plaster
or grout can be removed if lightly rubbed with detergent
on a damp cloth or sponge.
Drain Information
A drain/overflow assembly, purchased separately
from the bath, must be installed on the bath, water
tested, and connected to the sanitary system of the
house. After opening the carton, inspect for damage and
verify that the kit is of the proper finish. If a Jacuzzi
Whirlpool Bath drain/overflow is being installed, note
that the waste flange, strainer, overflow cover and cover
screws are packaged in a separate package within the
kit to protect the trim finish.
Follow the installation instructions provided with the
drain/overflow kit. After the drain is fully installed, test for
proper drainage. If the unit does not drain properly,
rectify this condition before proceeding with the installa-
tion. Jacuzzi Whirlpool Bath is not responsible for
removal and or reinstallation costs.
NOTE: Watertight installation of the drain is the
installer's responsibility. Any occurrence of drain
leakage is excluded from the Jacuzzi Whirlpool Bath
warranty coverage of this product.
Plumbing
Pump, jets and suction fittings for the whirlpool sys-
tem are factory plumbed in PVC schedule 40 piping.
All Jacuzzi Whirlpool Bath products are factory tested
for proper operation and watertight connections prior to
shipping. If leaks are detected, notify your Jacuzzi
Whirlpool Bath Dealer, do not install the unit.
Water Supply
Consult local authorities for plumbing code require-
ments in your area.
IMPORTANT: Proper installation of the fill spout
plumbing and compliance with local codes is the
responsibility of the installer. Jacuzzi Whirlpool
Bath does not warrant connections of water supply
fittings and piping, fill systems or drain/overflow
systems. Nor is it responsible for damage to the
bath which occurs during any installation proce-
dure.
CAUTION: A nonflammable protective barrier must
be placed between soldering work and bath unit to
avoid possible damage to the bath.
Paint, tar, or other difficult stains can be removed with
paint thinner, turpentine, or isopropyl alcohol (rubbing
alcohol).
Minor scratches which do not penetrate the color
finish can be removed by lightly sanding with 600-grit
wet/dry sandpaper. You can restore the glossy finish to
the acrylic surface of the bath with a special compound,
Meguiar's #10 Mirror Glaze. If that is not available, use
automotive rubbing compound followed by an applica-
tion of automotive paste wax.
Major scratches and gouges which penetrate the
acrylic surface will require refinishing. Ask your Jacuzzi
Whirlpool Bath dealer for special instructions.
Operation Summary
For complete instructions, see "Operating Instructions."
Before using the whirlpool bath, remove all construc-
tion residue and foreign materials.
Close the drain and fill the bath until water is at least
2" above the highest jet (see water line indicated on this
page.) Do not operate the whirlpool system at any
time if the jets are not completely immersed in water.
Your bath is equipped with the Magic Touch
whirlpool
ON/OFF switch. Activate the whirlpool system by push-
ing down on the Magic Touch switch button. To turn off
the whirlpool system, push down on the button again. To
change the direction of the water flow, swivel the jet
nozzle to the desired angle.
Two knobs located on the bath serve as controls for
the air induction system. The intensity of the hydromas-
sage whirlpool action is determined by the amount of air
inducted into the water. As the amount of air is in-
creased, the amount of whirlpool action will increase.
For maximum air induction, rotate the control knobs
fully counterclockwise to the largest circles. For fewer
air bubbles, decrease the amount of air induction by
rotating the control knob clockwise. When the knobs are
turned to the smallest circles, only water is being circu-
lated.
FILL TO AT LEAST 2"
ABOVE HIGHEST JET
2"
