ROUGHING-IN REFERENCE (Product Dimensions Shown)
3
TOP VIEW OF LEFT HAND WHIRLPOOL BATH UNIT
TOP VIEW OF RIGHT HAND WHIRLPOOL BATH UNIT
60"
60"
34-1/2"
34-1/2"
3"
11-3/4"
HOT/COLD STUB-OUT
FOR SHOWER
TOWER ENCLOSURE
OPTIONAL SHOWER TOWER BACKWALL. REFER
TO SHOWER TOWER ENCLOSURE INSTRUCTIONS
FOR ADDITIONAL INFORMATION
FINISH MATERIAL TO COVER STUDS
(BOTH SIDES)
MAKE 12x4'
CUTOUT IN
FLOOR TO
ALLOW FOR
DRAIN
9-7/8"
2"
1-3/4"
16"
11-1/4"
MOTOR/PUMP
LOCATION
60"
60"
34-1/2"
34-1/2"
3"
11-3/4"
HOT/COLD STUB-OUT
FOR SHOWER
TOWER ENCLOSURE
OPTIONAL SHOWER TOWER BACKWALL. REFER
TO SHOWER TOWER ENCLOSURE INSTRUCTIONS
FOR ADDITIONAL INFORMATION
FINISH MATERIAL TO COVER
STUDS (BOTH SIDES)
MAKE 12x4'
CUTOUT IN
FLOOR TO
ALLOW FOR
DRAIN
9-7/8"
2"
1-3/4"
16"
11-1/4"
MOTOR/PUMP
LOCATION
