Installing Batteries
1. Remove the battery cover from bottom of unit. Insert four
VA”
size batteries
as shown, taking care to observe the proper direction for each battery. Use of
alkaline batteries is recommended.
2. Replace battery cover.
Important Notes
l
Replace all four batteries if the low battery symbol appears on the display.
l Remove batteries if storing the unit more than six months without use. Never
leave dead batteries in an unit since they may leak and cause damage.
Memory data will be cleared when batteries are changed or become exhausted.
Proper Use of the Arm Cuff
1. Please relax and remain seated or reclined in a quiet location for 5 to 10
minutes prior to taking a measurement.
2. Remove any clothing on the upper arm so that the cuff can be placed directly on
the skin. Constriction of the upper arm caused by rolling up a shirt sleeve may
cause an inaccurate reading. Avoid this condition by completely removing the
garment causing the constriction.
3. Wrap the cuff around the upper arm as shown in the diagram on page 3. The
lower
edge
of the cuff (edge with air hose attached) should be about 1 inch
above the elbow. Position the cuff so that the hose runs along the inside of
the left arm.
4. Insert the straight plug on the end of the arm cuff air hose into the air connector
on the unit.
5. Relax for a few more minutes after the cuff is applied before beginning the
measurement.
Pane
3
