DEVICENET
BOARD
REVERSING
CONTACTOR
CLOSE
STOP
OPEN
DIG COM #1-Ve
0V AC
110V AC
24V DC +Ve
0V DC
24V DC +Ve
0V DC
5
6
7
9
8
51
10
12
11
14
13
37
38
L1
L2
L3
FS1
FS2
FS3
LIMIGARD
POSITION
SENSOR
1
2
3
4
31
32
42
43
AS1
AS2
AS3
AS4
"CLOSE"
POSITION
"OPEN"
POSITION
"CLOSE"
POSITION
"OPEN"
POSITION
17
18
19
SHOWN
WITH POWER
SUPPLY OFF
CONTROL PANEL
MOTOR
PE
3 PHASE
SUPPLY
TORQUE
SENSOR
MONITOR RELAY
REMOTE
LOCAL
S
T
O
P
(YES)
OPEN
CLOSE
(NO)
CONTROL
SUPPLY
CIRCUIT SHOWN WITH VALVE IN FULLY CLOSED POSITION AND WITH POWER OFF
STATUS FEEDBACK
OUTPUT SWITCHES
VIEW OF
TERMINAL
BLOCK
REMOTE
LOCAL
S
T
O
P
(YES)
OPEN
CLOSE
(NO)
ANALOG INPUT
8.EXACT END POSITION INDICATION
1.FUSES
FSI (PRIMARY)
FS2 (PRIMARY)
3.MAXIMUM EXTERNAL LOAD
TERMINALS 13 AND 14 (24V DC) - 10W MAX. EXT. LOAD
TERMINALS 11 AND 12 (110V AC) - 0V MAX EXT. LOAD
SUITABLE FOR DIGITAL INPUTS
ONLY, PROTECTED BY FS3.
5.CONTROL SIGNAL DURATION
REQUIRED CONTROL SIGNAL
DURATION = 250 - 350ms.
6.STATUS FEEDBACK OUTPUT SWITCHES
CLOSE
CLOSING
MID-TRAVEL
OPENING
OPEN
STOPPED
9.DEFAULT SETTING
ACTUATORS ARE NORMALLY SHIPPED WITH DEFAULT
SETTINGS AS SHOWN ON THIS DIAGRAM. THE "AS"
CONTACTS ARE SHOWN WITH VALVE IN FULLY CLOSED
POSITION. SEE CONTACT DEVELOPMENT BELOW.
7.CONTACT RATINGS
VALVE MOVING
VALVE JAMMED
MOTOR OVERTEMP
OVERTORQUE
CLOSE TORQUE SW
OPEN TORQUE SW
CLOSE INHIBIT
OPEN INHIBIT
ESD SIGNAL
NO ANALOG SIGNAL
LOST PHASE
LIMIGARD ACTIVE
HARDWARE FAILURE
LOCAL SELECTED
LOCAL STOP/OFF
MANUAL OVERRIDE
REMOTE SELECTED
OUTPUT SWITCH CONTACT DEVELOPMENT
VALVE POSITION
FULL
CLOSE
FULL
OPEN
FUNCTION
CLOSE LIMIT
AS4
OPEN LIMIT
AS3
CLOSE LIMIT
OPEN LIMIT
AS1
AS2
OUTPUT
SWITCH
ON TORQUE-SEATED VALVES THE LCD AND "AS"
CONTACTS, CONFIGURED AS END OF TRAVEL LIMITS,
AUTOMATICALLY PROVIDE EXACT END OF POSITION
INDICATION.
600V AC, 1A, 200kA Int RATING,
FAST ACTING 10.3 x 38.1mm TUBE.
FS3 (SECONDARY) - 0.1A, 250V, TIME DELAY,
5 x 20mm, GLASS TUBE
AS1,2,3 AND 4 - 5.0 AMPS AT 125V AC, 30V DC (250V AC-CENELEC)
MONITOR RELAY - 5.0 AMPS AT 250V AC, 30V DC
NOTES
TRANSFORMER TAPPING OPTIONS
TYPE
TAPPING
A
220V
380V
415V
460V
B
TYPE
TAPPING
115V
220V
525V
575V
TYPE
TAPPING
A
220V
380V
415V
460V
B
TYPE
TAPPING
115V
220V
525V
575V
TRANSFORMER TAPPING OPTIONS
DEFAULT SETTING
SEE NOTE 6 AND 9
2.AUXILIARY INPUT
AUXILIARY INPUT
SEE NOTE 2
52
21
DIG COM #2-Ve
DIG COM #3-Ve
2 mA / 24V DC
MAX LOAD - 10 mA / 110V AC
MAXIMUM "OFF" 5.0V AC/DC
SIGNAL THRESHOLD - MINIMUM "ON" 19.2V AC/DC
4.REMOTE INPUTS
REMOTE
INPUTS
SEE NOTE 4
INPUT 2
INPUT 1
INPUT 0
120 OHM, 1/4W TERMINATION RESISTORS MUST BE CONNECTED
AT EACH SEGMENT END.
SHIELDS TOGETHER TO ENSURE PROPER SHIELDING OF ENTIRE NETWORK.
ON EACH SEGMENT. CONNECT REMAINING INDIVIDUAL NETWORK CABLE
WIRING IS TO CONNECT SHIELD TO TERMINAL 48 FOR ONLY ONE UNIT
AND CHASSIS GROUND FOR SURGE PROTECTION. PREFERRED NETWORK
CUSTOMER IS REQUIRED TO CONNECT WIRE BETWEEN TERMINAL 30
SEE NOTE 11
RECOMMENDED DEVICENET CABLE IS BELDEN 3084A OR EQUAL.
15
16
48
SHIELD
NETWORK DATA (+)
NETWORK DATA (-)
0% OPEN
STATUS OK
1
2 3 4 5
6 7
8
9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
0
2
3
2
4
2
5
2
6
2
7
2
8
2
9
3
0
3
2
3
3
3
4
3
1
3
5
3
6
3
7
3
8
3
9
4
0
4
1
4
2
4
3
4
4
4
5
4
6
4
7
4
8
4
9
5
0
5
1
5
2
2
2
2
1
L1
L2 L3
GROUNDING
LUG
0% OPEN
STATUS OK
NETWORK +24V
NETWORK 0V
29
41
39
28
-ve ANALOG COMMON
+ve ANALOG INPUT-1
+ve ANALOG INPUT-2
40
(MODUTRONIC)
STANDARD SIGNAL 4-20 mA
INPUT IMPEDANCE = 250 OHMS
INPUT CAPACITACNE = 0.1uf±30%
99% ACCURACY
CONFIGURABLE SCALING
10.ANALOG INPUT
BACK-UP 24v DC UPS POWER MAY BE CONNECTED
TO TERMINAL'S 37 AND 38. MAXIMUM CURRENT
DRAW IS 1 AMP. THIS POWERS ALL CONTROLS FOR
LOCAL INDICATION AND CONFIGURATION. ANALOG OUTPUT AND ALARM
RELAYS SUPPLIED WILL BE POWERED FOR UNITS MANUFACTURED
SUBSEQUENT TO Q1/2003. REVERSING CONTACTOR WILL NOT
BE POWERED. CUSTOMER SHOULD SUPPLY EXTERNAL FUSE AS
REQUIRED BY LOCAL ELECTRICAL CODES.
THE ACTUATOR STATUS CONTACTS (AS) AND ALARM RELAYS (AR)
MAY BE INDIVIDUALLY CONFIGURED AS NORMALLY OPEN OR NORMALLY
CLOSED LATCHED CONTACTS OR AS BLINKER CONTACTS TO INDICATE
ONE OF THE FUNCTIONS LISTED BELOW:
BLU
BLK
WHT
RED
11.DEVICENET
EGND
30
INPUTS 0,1,2 ARE FIELD CONFIGURABLE (FIRMWARE VERSION 04\08.00 OR LATER)
FOR CLOSE INHIBIT, OPEN INHIBIT, CLOSE/OPEN INHIBIT, USER INPUT, OR ESD. IN
ADDITION, INPUT 2 MAY BE CONFIGURED FOR CSE REMOTE SELECTED INDICATION.
DEFAULT INPUT CONFIGURATION: INPUT 0 - ESD, INPUT 1 - OPEN INHIBIT, INPUT 2 -
CLOSE INHIBIT
SEE INSTALLATION AND OPERATION MANUAL FOR CONFIGURATION PROCEDURES.
