29
Limitorque MX DeviceNet Field Unit FCD LMENIM2328-00 – 11/05
flowserve.com
Table 4.34
Bit 15 - 11 Bit 10 - 9 Bit 3
Unused Scaling 0 =
0 – 100 1 =
0 – 255 2 =
0 -4095 3 =
Reserved
Unused
4.4.1 Identity Object Instance Attributes
Table 4.35 – Identity Object Instance Attributes
Attribute
ID
Access Rule Name Data Type
Description of
Attribute
Semantics of Value
1 Get
(NV-RO)
Vendor ID UINT Identification of
each vendor by
number
966 (3C6hex)
(Note 1)
2 Get
(NV-RO)
Device Type UINT Indication of general
type of product
00hex
(Generic Device)
3 Get
(NV-RO)
Product Code UINT Identification of a
particular product
of an individual
vendor
19800 (4D58hex)
(Note 2)
4 Get
(NV-RO)
Revision STRUCT
of
Revison of the item
the Identity Object
represents
1.1
(Note 3)
Major Revision USINT Major Revision of
DeviceNet
Limitorque Interface
Minor Revision USINT Minor Revision of
DeviceNet
Limitorque Interface
5 Get
(V-RO)
Status WORD Summary status of
device
(Note 4)
6 Get
(NV-RW)
Serial Number UDINT Serial number of
device
(Note 5)
7 Get
(NV-RW)
Product Name SHORT_
STRING
Human readable
identification
”Flowserve MX”
(Note 6)
8 Get
(V-RO)
State USINT Present state
of the device as
represented by
the state transition
diagram
10 Get/Set
(NV-RW)
Heartbeat Interval USINT The nominal interval
between heartbeat
messages in
seconds
The default value
is 0. Zero disables
transmission of the
heartbeat message.
100 Get
(V-RO)
EEPROM Failure BOOL Result of EEPROM
checksum
verification
0 = EEPROM contents
is o.k.
1 = EEPROM contents
may be defective due
to checksum error
The further optional attributes
Configuration Consistency Value (Attribute ID 9)
Active Language (Attribute ID 11)
Supported Language List (Attribute ID 12)
•
•
•
