PART NO. DESCRIPTIONREF NO QTY.
Lift Group
Footnotes
1 1960071 2 WASHER, 3/8, Black
2 1723194A 2 LINK, Lift
3 2154177 4 SPACER
4 1922755 4 WASHER,3/8, Black
5 1921971 2 CAPSCREW, Hex Head, 3/8-16 x 1-3/4, Black
6 1722357 1 CAPSCREW, Hex Washer Head, 5/16-18 x 4-1/2, Black
7 1917372 2 NUT, Hex, 5/16-18, Black
8 1723202A 1 ANCHOR, Spring
9 1921719 2 CAPSCREW, Hex Head, 5/16-18 x 2-1/2
10 1723499 1 RETAINER, Spring
11 1935255 1 NUT, Speed, 5/16-18
12 1675232 1 SPRING, Extension, 9" Long
13 1930645 4 NUT, Hex Flange Lock, 3/8-16, Black
14 1723203A 1 BAR & HUB ASSEMBLY
15 2815523 1 PIN, Spring, 5/16 x 1-1/2
16 1920415 4 CAPSCREW, Hex Head, 3/8-16 x 1-1/4, Black
17 1931277 2 NUT, Hex Flange Whiz Lock, 5/16-18, Black
18 1722291 1 GRIP, Lift Lever
19 1723124 1 BUTTON, Red
20 1960674 1 NUT, Push, 1/4, Black
21 1723321 1 SPRING, Compression, 3.85" Long
22 1723200A 1 HANDLE ASSEMBLY, Lift
23 1723224 1 ROD
24 1723285A 1 QUADRANT, Lift
25 1920397 1 NUT, Hex Lock ESNA, 1/4-20, Black
26 1720599 1 LATCH "U" Wire
27 1930591 4 CAPSCREW, Hex Head, Whiz Lock, 5/16-18 x 3/4, Black
28 1921159 1 CAPSCREW, Hex Head, 1/4-20 x 2-1/4, Black
29 1665374A 1 STRAP
30 1723529A 1 BRACE, Support
31 2860641 2 NUT, Hex Lock Aluminum Insert, 3/8-16
32 1928352 2 NUT, Hex Whiz Lock , 3/8-16
The above parts group applies to the following Mfg. Nos.:
2005
25
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694772 - Lancer
1694785 - 4416XL
1694786 - Lancer
1694787 - 4416XL
TP 400-4206-01-LN-SM
