1-4 Attach Vertical Bracket
3 6
4
5
02
Screws
01
01
01
3. Vertically center the vertical TV bracket
02
.
4. Visually line up the locator hole in the bottom horizontal TV bracket
01
with a hole in the vertical TV bracket
02
.
5. Press and turn a spring screw to secure the vertical TV bracket
02
in place. Push and tighten the remaining three spring screws.
NOTE: You may need to slide the vertical TV bracket
02
up or down while pressing in the spring screw to find the first mounting hole.
6. Tighten the 4 screws (PAGE 5) on the horizontal TV brackets
01
.
01
Spring
Screw
Spring Screw
Locator Hole
TV Bracket
Hole
