19
REMOVING THE TV
1. Disconnect all cables from the TV.
2. Pull out the safety release pin on vertical TV bracket
02
and turn counterclockwise until the pin locks in place.
3. Pull and hold the release cord while pulling the bottom of the TV outward.
4. Lift the TV off the arm assembly/wall plate
11
to remove.
NOTE: To hang the TV back on the arm assembly/wall plate
11
, follow Step 3 on PAGES 15 and 16.
HEAVY! You may need assistance with this step.
Release Cord
Safety
Release Pin
11
02
1
2
3
4
