Power Tools EZConfig Utilities 185
E-EQ-MX6RG-E-ARC MX6 Reference Guide
WEP Section
This child section of the 802.11b section defines the WEP (Wired Equivalent Privacy) parameters
for linking to a network.
Key Description Available Values
Authentication Specifies the authentication mode.
Default value: 0
0=Open; WEP keys are not used
1=Shared; WEP keys are used
2=Automatic; auto-discriminates
between Open and Shared
authentication modes
Encryption Specifies the encryption method.
Default value: 0
0=No Encryption
1=WEP 64-bit RC4 encryption
2=WEP 128-bit RC4 encryption
Active Key Specifies which WEP key to use to
encrypt transmitted data. Note: These
keys are used only if 1 or 2 is selected as
the Authentication method.
Default value: 0
X=Keys 1–4; key data is specified
in the Keys 1–4 below.
Key 1 Defines Key 1 for the Active Field key.
Default key: None
Key 2 Defines Key 2 for the Active Field key.
Default key: None
Key 3 Defines Key 3 for the Active Field key.
Default key: None
Key 4 Defines Key 4 for the Active Field key.
Default key: None
ASCII=Use quotes for the value;
e.g., "hello")
Hex=Type the pair of hex values in
a row; e.g., AFB0FF415A
64-bit encryption=Length must be 5
characters or 5 hex pairs
128-bit encryption=Length must be
13 characters or 13 hex pairs
Note: The keys in this section are encrypted
Bluetooth Section
The keys in this section enable the Bluetooth radio and configure a Bluetooth printer as a Favorite.
If there is no Bluetooth radio installed in the mobile device, disable this section.
Key Description Available Values
Enable
Enable and disable the Bluetooth radio. This is the
top level of the tree; printer settings are in a child
section.
Default value: 1
0=Disable
1=Enable; the GSM radio is
disabled automatically
Default
Printer
This is a child section that configures a printer as a Favorite Bluetooth Device. By
entering the necessary information from the Bluetooth printer in the
DeviceConfig.EXM file, and then distributing that file to a group of mobile
devices, you can bypass the manual process of setting up a printer as a Bluetooth
Favorite on each device.
Address
Bluetooth MAC Address of the printer
Default: N/A
MAC Address
