Settings Options 109
E-EQ-MX6RG-E-ARC MX6 Reference Guide
Scanner
Access: Start | Settings | System tab | Scanner
Disable the internal scanner when you want to run the Scan Demo or Imaging Demo programs.
Refer to section titled “Demo Programs” earlier in this guide.
Disable WEDGE when you want to capture barcode data in “block mode” using the scanner
functions provided in the LXE API. Refer to the “MX6 Software Development Kit” Part ID
MX6A502PPCSDK.
Version 7.03
Factory Default Settings
Main
Enable internal scanner Enabled
Send Key Messages (WEDGE) Enabled
Tethered scanner on COM 1 Disabled
COM 1
Baud Rate 9600
Data bits 8
Stop bits 1
Parity None
Figure 4-30 V 7.03 Scanner Settings
