Configuring and Expanding Your Computer
Installing RAM Modules
36 Startup Guide
Installing RAM Modules
The notebook provides an optional memory expansion slot for installing up to two RAM
expansion modules. Use HP PC-133 or higher SDRAM modules only.
CAUTION
Static electricity can permanently damage computer chips. Handle the RAM module
only by its three non-connector edges. Otherwise, you may damage the module due
to electrostatic discharge. Always discharge the static electricity from your body by
touching the metal shielding around the connectors on the rear of the computer
before touching or installing the memory module.
You’ll need a small Phillips screwdriver to complete this procedure.
1. Click Start, Turn Off Computer, Turn Off.
2. Important: unplug the AC adapter, if present, and remove the battery.
3. Remove the RAM expansion cover located on the bottom of the computer.
4. Insert the RAM expansion module into the connector at about a 30° angle until it’s
fully inserted. Then press down at both sides of the module until it latches.
5. Replace the RAM expansion module door.
6. Insert the battery.
