HP LaserJet P2050 Series Printer – Manage and Maintain
© 2008 Copyright Hewlett-Packard
Development Company, L.P.
1
www.hp.com
Tray and bin capacity
How do I? Steps to perform
Paper
● Maximum stack height: 5 mm (0.3 inch)
● Equivalent to 50 sheets of 75 g/ m
2 (20 lb) bond
Envelopes
● Up to 10 envelopes
Labels
● Maximum stack height: 5 mm (0.3 inch)
Tray 1
Transparencies
● Maximum stack height: 5 mm (0.3 inch)
Paper
● Equivalent to 250 sheets of 75 g/m2 (20 lb) bond
● Maximum stack height for A6 paper: 15 mm (0.59 inch)
Tray 2
Transparencies
● Maximum stack height: 26 mm (1.0 inch)
Paper
● Equivalent to 500 sheets of 75 g/m2 (20 lb) bond
● Maximum stack height for A6 paper: 40 mm (1.6 inches)
Optional 500-sheet Tray 3
Transparencies
● Maximum stack height: 54 mm (2.1 inches)
Standard top bin
Paper
● Up to 125 sheets of 75 g/m2 (20lb) bond
