Item Component Spare part number
For use in the United States 701976-001
(3) Top cover (includes TouchPad and 2 TouchPad buttons): 684338-001
(4) Fan (includes cable) 641839-001
(5) Heat sink (includes replacement thermal material) 693371-001
(6) System board equipped with the Mobile Intel HM76 chipset and a graphics
subsystem with UMA memory (includes replacement thermal material)
710658-001
(7) Speaker assembly (includes cable) 641840-001
(8) Intel Celeron B840 1.90-GHz processor (1333-MHz FSB, 2.0-MB L3 cache,
35 W; includes replacement thermal material)
664663-001
(9) Base enclosure (includes rubber feet, service cover release latch assembly, and
battery release latch assembly)
687224-001
Rubber Kit (not illustrated, includes display bezel left and right rubber screw covers,
base enclosure front and rear rubber screw covers, top cover rubber bumper)
641831-001
Latch Kit (not illustrated, includes service cover release latch assembly components
and battery release latch assembly components)
684339-001
(10) Battery (Li ion):
9-cell, 100-Wh, 3.00-Ah 631243-001
6-cell, 62-Wh, 2.80-Ah 628668-001
(11) 4-GB memory module (PC3-12800, 1666-MHz, DDR3) 641369-001
(12) Broadcom 43228 802.11abgn 2×2 Wi-Fi Adapter 669832-001
(13) RTC battery 651948-001
(14) DVD-ROM drive (includes optical drive bezel and optical drive bracket) 716387-001
(15) 16-GB SATA solid-state drive (does not include bracket or screws): 716388-001
Hard Drive Hardware Kit (not illustrated, includes bracket and screws) 642774-001
(16) Service cover:
Includes country of origin label 684326-001
Includes regional configure to order (RCTO) with “made in China” label 699324-001
14 Chapter 3 Illustrated parts catalog
