Field Replaceable Units
FRU Removal and Replacement
134
Figure 46 Removing the EISA Slider and Retainer
3 Remove the screw from the EISA retainer and remove it,
as shown in Figure 46.
4 If you are removing a PCI, EISA, or GSC board grasp it
by the edge with both hands and pull it straight out.
Perform Steps 4 through 1 in reverse order to replace the
board.
EISA Slider
EISA Retainer
