Using this Guide
Introducing Your
HP DesignJet 800 Printer
Front View of Printer Printer Connections
Media & InkIntroduction Front Panel Other
Printer
Options
Index
Solutions
• Speed: The HP DesignJet 800 printer delivers speeds of 250ft
2
/hour and color CAD line drawings on bond
media are printed up to three times faster than its predecessor the, the HP DesignJet 700 series printers.
Because the printer contains a virtual computer and printing is continuous, data is received by the network
card and quickly processes and prints using embedded processors and large memory (96MB RAM and 6GB
hard disk) included within the printer.
• HP Premium Printing Material: The HP DesignJet 800 A0+/E+ size and D/A1 size printing systems accept a
wide range of roll and sheet media from 24 inches/609.6 mm (
D/A1 size) to 42 inches/1066.8 mm (A0+/E+ size)
wide including
HP Satin Poster Paper, HP High-Gloss Photo Paper and HP Heavyweight Coated Paper. In
addition, the
HP DesignJet 800 printer accepts a wide range of media for technical applications.
• Complementary Media Program (CMP): The CMP helps HP customers grow their businesses by referencing third-
party printing material choices to ensure maximum HP DesignJet printer flexibility and printing solutions.
