Monitoring and Analyzing Switch Operation
Status and Counters Data
ProCurve(config)# show modules details
Status and Counters - Module Information
Chassis: 8212zl J8715A
Slot Module Description
Serial Number: SG560TN124
Serial Number Status
----- ----------------------------------------
MM1 ProCurve J9092A Management Module 8200zl
SSM ProCurve J8784A System Support Module
C ProCurve J8750A 20p +4 Mini-GBIC Module
GBIC 1: J4859B 1GB LX-LC
GBIC 2: J4859B 1GB LX-LC
--------------
AD722BX88F
AF988DC78G
446S2BX007
4720347DFED734
4720347DFED735
-------
Active
Active
Active
Figure B-10. An Example of the show modules details Command for the 8212zl Showing SSM and Mini-
GBIC Information
Note On ProCurve 3500yl and 6200yl series switches, the mini-GBIC information
does not display as the ports are fixed and not part of any module.
Port Status
The web browser interface and the console interface show the same port
status data.
Menu: Displaying Port Status
From the Main Menu, select:
1. Status and Counters …
4. Port Status
B-14
