4–46 Maintenance and Service Guide
Removal and replacement procedures
6. If it is necessary to replace the display hinges:
a. Remove the eight Torx T8M2.5×4.0 screws 1 that secure the display hinges to the display enclosure.
b. Remove the display hinges 2. The display hinges are available in the Display Hinge Kit, spare part number
581094-001.
