hp photosmart 1315 color printer
11
5 Remove the plastic tape from the new print cartridge:
• Take the print cartridge out of its package.
• Grasp the tab and peel off the plastic tape.
Make sure you only remove the clear tape from the nozzles and
leave the copper-colored contact.
Note: Do NOT touch the ink nozzles or the copper contacts.
Touching these parts may cause print cartridge failure.
6 Insert the print cartridge:
• Hold the cartridge handle and with the copper side going in first,
carefully insert the print cartridge into the cradle. Take caution
and avoid tearing the copper-colored contacts against the
printer’s contact pins.
• Close the cradle latch to
lock the print cartridge in
place.
7 Close the top cover.
8When the LCD prompts you,
load plain paper in the IN
tray if you do have not
already loaded paper. For
more information, see “loading paper” on page 7.
Handle
Color print cartridge
HP #45 (51645)
Do not touch the
ink nozzles or the
copper contacts
Plastic tape
Plastic tape
Black print cartridge
HP #78 (C6578)
