Instruction Manual
IB-106-340C Rev. 4.1
July 2004
11-4 Replacement Parts Rosemount Analytical Inc. A Division of Emerson Process Management
Hazardous Area Oxymitter 4000
Table 11-2. Replacement Parts for Electronics
Figure and
Index No. Part Number Description
9-3, 1, 17 5R10145G01 Cover, Blind
9-3, 1A 08732-0007-0002 Cover, with Window
9-3, 2 3D39861G01 Electronic Assembly
9-3, 4 4849B72H01 Membrane Keypad English
9-3, 4 4849B72H02 Membrane Keypad German
9-3, 4 4849B72H03 Membrane Keypad French
9-3, 4 4849B72H04 Membrane Keypad Spanish
9-3, 4 4849B72H05 Membrane Keypad Italian
9-3, 4A 6A00115G01 LOI Module (Local Operator Interface)
9-3, 11 4850B86G01 Housing
9-3, 15 08732-0002-0001 Termination Block Standard
9-3, 15 08732-0002-0002 Termination Block Transient Protected
9-3, 17A 120039078 O-Ring
9-3, 31 120039076 O-Ring
9-4, 2 3D39861G01 Electronic Assembly
9-4, 4 4849B72H01 Membrane Keypad English
9-4, 4 4849B72H02 Membrane Keypad German
9-4, 4 4849B72H03 Membrane Keypad French
9-4, 4 4849B72H04 Membrane Keypad Spanish
9-4, 4 4849B72H05 Membrane Keypad Italian
9-4, 4A 6A00115G01 LOI Module (Local Operator Interface)
9-4, 11 5R10146G04 Housing
9-4, 15 08732-0002-0001 Termination Block Standard
9-4, 15 08732-0002-0002 Termination Block Transient Protected
9-4, 17A 120039078 O-Ring
9-4, 24 6A00091G02 Junction Box
9-4, 26 120039076 O-Ring
9-4, 29 4849B92G20 Connecting Cable, Signal
9-4, 30 4849B92G21 Connecting Cable, Heater
9-4, 31 6A00122G01 Cable Assembly, 20 ft. (6 m)
9-4, 31 6A00122G02 Cable Assembly, 40 ft. (12 m)
9-4, 31 6A00122G03 Cable Assembly, 60 ft. (18 m)
9-4, 31 6A00122G04 Cable Assembly, 80 ft. (24 m)
9-4, 31 6A00122G05 Cable Assembly, 100 ft. (30 m)
9-4, 31 6A00122G06 Cable Assembly, 150 ft. (46 m)
9-4, 31 6A00122G07 Cable Assembly, 200 ft. (61 m)
9-4, 32 3D39866G01 Termination Block, Standard, Remote Probe Head
9-4, 32 3D39866G02 Termination Block, Transient Protected, Remote Probe
Head
9-4, 34 4850B86G01 Housing
