Page 15
OUTER CASE OPTIONS AND AVAILABLE HITCH CONFIGURATIONS
DA10 OPTIONS
33. 03412-?? 1 Outer Case w/ no mount
34. 03548-?? 1 Outer Case w/ 6 hole mount
35. 03884-97 1 Outer Case w/ 50° mount (primed red)
36. 07105-97 1 Outer Case w/ channel mount (primed red)
37. 07718-97 1 Outer Case w/ angle mounts (primed red)
38. 11043-97 1 Flat Mount Inner Slide Tube (primed red)
39. 11051-?? 1 2-5/16" Lever Lock Coupler Slider (drop tube)
40. 05593-?? 1 10,000 lb. Clevis
41. 09557-?? 1 Pintle Ring (20,000 lbs. Capacity)
42. 02434 2 5/8"-11UNC x 4 1/2" Hex Head Bolt Gr.5
43. 03730 4 5/8"-11UNC Stover Lock Nut
44. 02587 2 5/8"-11UNC Nylon Insert Lock Nut
45. 05557-?? 1 2-5/16" Bulldog Coupler
46. 11046-?? 1 2-5/16" Lever Lock Coupler Slider Tube (straight)
47. 11047-97 1 12” Channel Down Inner Slide Tube (primed red)
48. 04051 4 5/8"-11 UNC x 1-1/2" Hex Head Bolt Gr.5
49. 07678-?? 1 2-5/16" Lever Lock Coupler
Please order replacement parts by
PART NO. and DESCRIPTION and
COLOR.
44
44
42
48
48
43
43
47
46
49
(2 5/16”) RATED AT 20000#
48
48
45
48
48
43
43
(2 5/16”) RATED AT 12500#
42
41
48
48
48
RATED AT 10000#
48
43
33 34
35
36
40
39
38
37
Note: -?? = -95 Plated -97 Primed Red
Indicate color when ordering parts
The weight rating of the coupler is dependent on
the correct bolts being used. You must use the bolts
provided with the product. If you are missing bolts,
refer to your Operator’s Manual and obtain replace-
ments from Demco, or use the exact size, grade, and
number of bolts as specified. Using the wrong size,
grade, or number of bolts will reduce the weight rat-
ing of the coupler and could cause separation of
your towing equipment from the towing vehicle. If
you have questions about the correct bolts for your
application call Demco at any of the following tele-
phone numbers:
(712) 725-2311
(712) 725-2302
1-800-543-3626
FAX: 1-800-845-6420
WARNING: TO AVOID PERSONAL INJURY
OR PROPERTY DAMAGE, OBSERVE THE
FOLLOWING INSTRUCTIONS:
!
(2-5/16”)RATED AT 20000# (2-5/16”)RATED AT 20000# RATED AT 20000#
48
48
