KEEP THIS MANUAL WITH THE SCOOTER
This manual should be kept with the vehicle and should remain with the scooter when resold or otherwise transferred to a
new owner or operator. This manual contains important safety information and instructions which should be read carefully
and thoroughly before the rider operates the scooter.
LICENSES, REGISTRATION AND INSURANCE
Although this scooter is equipped for legal operation in the United States, prior to operation of this scooter you must
consult your state and local government ordinances concerning driver’s license requirements, license plates and proper
registration. Before operating this scooter, consult your agent concerning proper insurance coverage in your state.
• Write the Vehicle Identification Number (VIN) of your scooter here for future reference. When speaking to your dealer,
you may need to provide the model number and the VIN, found on the VIN badge located on the back side of the front
fairing. Find your model number on the Certificate of Origin that came with your scooter.
Model Number (circle one): 50SP06BK 50SP06RD VIN number _______________________________________
If you experience problems, are missing parts, or need service or repairs for your scooter, contact your local dealer.
Engine ....................................................4-Stroke Air Cooled
Dispacement..............................................................49.5 cc
Cylinders .............................................................................1
Starter..........................................................Electric and Kick
Transmission ..................................................Automatic CVT
Transmission Oil...............................Multi-weight SAE 85/90
Transmission Oil Capacity ..........................4.1 oz (0.12 liter)
Front Tire...........................................................120/70 – 12
Rear Tire.............................................................130/70 – 12
Tire Pressure.....................................26 psi Front/32 psi Rear
Front Brake .....................................................................Disc
Rear Brake ....................................................................Drum
Brake Fluid .............................................Type 3/Type 4 DOT
Brake Fluid Capacity .......................................1.0 oz (30 ml)
Suspension Front ...................................................Telescopic
Suspension Rear ...........................................Damping Shock
Fuel Capacity ...............................................1.05 gal (4 liter)
Fuel Type ...............................Unleaded 90 Octane or better
Gas Mileage* ....................................117 mpg (50 km/ liter)
Driving Range* .......................................155 miles (250 km)
Engine Oil.....................................Multi-weight SAE 15W-40
Engine Oil Capacity....................................0.8 qt (0.75 liter)
Maximum Speed on Flat ......................29.8 mph (48 km/h)
Seat Storage .........................................0.60 cu ft (16.9 liter)
Luggage Rack Load Capacity .........................10 lbs (4.5 kg)
Length ....................................................72.8 in (1850 mm)
Width**.....................................................26.8 in (680 mm)
Height**..................................................44.9 in (1140 mm)
Dry Weight .....................................................198 lb (90 kg)
* Estimate for 180 lb load on level ground
** Not including mirrors
All specifications are subject to change without notice.
Introduction
Specifications
Vehicle Record
1
WARNING
The engine exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects or other
reproductive harm.
Safety Precautions
