Description of Features, continued
7
THROTTLE (RIGHT HANDLEBAR GRIP)
• ACCELERATE: Twist the throttle toward you.
• D
ECELERATE:
T
wist the throttle away from you or loosen your grip and the throttle will automatically return
to the idle position.
HELMET STORAGE HOOK
• Use the hook to store your helmet when not in use. Maximum weight for the helmet storage hook: 6.6 lbs. (3 kg).
BRAKES
• FRONT BRAKE LEVER: The FRONT brake lever is attached to the RIGHT handlebar.
• REAR BRAKE LEVER: The REAR brake lever is attached to the LEFT handlebar.
• For more information about using the brakes, see “Riding the Scooter”, page 10. To adjust brakes, see “Front and Rear
Brake Adjustment” on page 12.
KICK STARTER
• Use the kick starter to start the scooter or prime the engine in the following situations:
- If the scooter has been driven less than 100 miles (160 kilometers).
- In cold or wet weather.
- If the fuel tank has run completely dry (and more fuel has been added).
- If the scooter has been stored for more than two weeks.
- If the scooter fails to start using the electric starter button.
- If the battery is discharged.
• The kick starter can be used to “prime” the fuel system prior to using the electric start button. See “Starting the Scooter”,
pages 8 and 9 for detailed instructions on using the kick starter.
CENTER STAND
• Always use the center stand on level ground.
• To extend the center stand and park the scooter, grasp the left handlebar grip and the luggage rack with your right
hand. Place your right foot on the foot peg of the center stand and push straight down. The rear wheel will raise slightly
as the scooter comes to rest on the center stand.
• To retract the center stand, grasp both handlebar grips and push the scooter forward. NOTE: Be sure your feet and legs
are clear of the center stand. The center stand has a strong spring and will retract under the scooter very quickly.
LUGGAGE RACK
• Evenly distribute the load on the luggage rack and secure with straps.
• Do not attach anything to the handlebars, fenders or footrests.
VIN BADGE AND ACCESS PLATE
• You will need your V
ehicle Identification Number when registering your scooter with your local government or contacting
your dealer. The VIN appears in two places: on the VIN badge, located on the back side of the front fairing, and under
the VIN access plate.
AUTOMATIC TRANSMISSION
• Your new scooter has an automatic transmission that does not require the use of a clutch or gear shift.
WARNING
• Maximum load for the luggage rack is 10 lbs. (4.5 kg).
NEVER exceed maximum load capacity for the
scooter. Combined weight of the rider, gear and any accessories must never exceed maximum load capacity of
225 lbs. (102 kg).
Overloading can impair the stability and performance of the scooter, possibly
causing an accident.
