Infrared Ear Thermometers iCcurate User Manual
5
Replacing the Battery
1. By using screw driver carefully to release battery cover. Before
Changing the battery be sure the system is already power off.
2. Press the battery holder lock to release the battery.
3. Remove the battery and replace with a new one, type CR2032, Make sure the positive pole of the battery facing up.
4. Slide the battery cover back in until it snaps in place.
Do not dispose of used batteries in household waste. Take them to special local collection sites.
5. In case, if system is latched up after changing battery. You may not follow up the process of rule one. Just take off battery, waiting 30 sec, then load
battery again.
Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire.
Product Specifications
Displayed temperature range: 34℃ to 42.2℃ (93.2℉ to 108℉)
Operating ambient temperature range: 10℃ to 40℃ (50℉to 104℉)
Display Resolution: 0.1℃ or 0.1℉
Storage & transportation temperature:
-20℃ to 50℃ (-4℉~122℉),85%RH,non-condensing for one month.
Not AP or APG equipment.
This product is IPX0 grade.
The manufacturer recommends to verify the accuracy by Rosewill Medicare’s Customer Department
Every 2 years.
Accuracy:
Measurement Range Error
<35.5 °C(89.6 °F) or > 42 °C(107.6 °F)
35.5 to 42 °C(86.9 to 107.6 °F)
±0.3℃(±0.5℉)
±0.2℃(±0.4℉)
Accuracy is determined under laboratory conditions in the calibration mode with a typical probe
Cover installed.
Storage temperature ranges: -20℃ to 50℃ (-4℉ to 122℉)
Storage humidity (max): 95%RH, non-condensing
Display Mode: Oral (The actual measured ear canal temperature plus mathematical adjustment to approximate the familiar oral range. However, this is
not necessarily the same as an oral temperature measured at the same time).
EL back light (DX version only).
Data memory: Up to 8 temperature readings can be stored.
Power supply: One lithium battery, type CR2032
Battery life: 2 years / 4000 measurements
Size: 119mm X 60mm X 28mm
Weight: approx. 65g, battery included.
