GETTING STARTED
Position the main unit, rain gauge, and thermo sensor
within effective range:
• Rain gauge - 328 feet / 100 meters
• Thermo sensor - 98 feet / 30 meters
IMPORTANT It is recommended that you follow the
sequence below when setting up the units:
1. Set up the main unit.
2. Set up the rain gauge, then press and hold
SEARCH on the main unit and wait until you receive
a signal.
3.
Set up the thermo sensor, then press and hold SEARCH
on the main unit and wait until you receive a signal.
4. In the event that you do not obtain a signal from a
remote unit please repeat the process above.
MAIN UNIT
1. Insert the batteries, matching the polarity (+ and -)
as shown in the battery compartment.
2. Press RESET, or press and hold SEARCH on the
main unit to initiate operation. The reception icon
on the main unit will blink while it is searching for
the sensor or rainfall gauge.
NOTE Every time the battery in the main unit is
changed, repeat installation before use.
RAIN GAUGE (PCR122)
1. Insert the batteries, matching the polarity (+ and -)
as shown in the battery compartment.
2. Mount the rain gauge on a level surface.
"
A
A"UM
3
1.5V
"
A
A"UM31.5V
"AA"UM31.5V
"AA"UM31.5V
RGR126(R13)-4(final) 4/6/05, 5:46 PM6
