Omron Healthcare 705IT Blood Pressure Monitor User Manual



English
17
16
Before measuring, stretch your back and sit up
straight, breath normally 5-6 times, relax your
shoulders, arms and entire body.
Slightly bend and support your elbow (e.g. on a
table).
Do not move, talk or touch the device during
measurement.
Stress influences your blood pressure, so try to
relax before taking a measurement.
To compare results, measurements must always
be taken from the same arm.
Do not place the cuff over thick clothes and do not
roll up your sleeve if it is too tight.
Align the cuff with the height of your heart (breast
height). If necessary use a pillow or cushion.
Coldness raises your blood pressure. It is
recommended to measure at room temperature
(+20°C).
Relax before measurement. If necessary go to the
bathroom before measurement.
Do not measure directly after bathing.
If you wish to interrupt measurement prematurely,
press the (O/I) button. Inflation is stopped and the
air is automatically released from the cuff.
Blood pressure measurements taken in a moving
vehicle may be influenced by vibration.
If an error has occurred during measurement is
displayed. Please refer to the next chapter.
The monitor should be switched off after
measurement to avoid running down the batteries
unnecessarily. If you forget to do so, the monitor
switches itself off automatically after 5 minutes.
E
Hints on taking
blood pressure
readings
Failure, causes and rectification
Failure and their possible causes
Incorrect measurement is indicated by
1. A correct reading could not be obtained
because measurement was disturbed by
movement of the body.
2. The cuff is not fitted correctly.
3. Your clothing has constricted your
blood flow.
4. There is still air in the cuff when the
monitor is switched off.
The (START ) button was pressed
before the ( ) symbol was displayed.
The blood pressure values displayed are
extremely low or high, or they are
implausible.
The display does not light up when the
(START ) button is pressed.
1. The batteries are exhausted.
2. The +/- poles of the batteries have been
reversed.
3. The battery contacts are dirty.
The batteries are weak or exhausted.
The cuff pressure does not rise
although the pump motor can be heard.
problem with mem. function
Er
E
Rectification
1. Repeat the measurement keeping
perfectly still. Do not move your arm and
do not speak.
2. Check that the cuff is correctly fitted.
Then repeat the measurement.
3. Remove the item of clothing which
caused the constriction.
4. The unit may be defective. Please have
it examined and, if necessary, repaired
by OMRON.
Wait for the ( ) symbol indicating
readiness before you press the (START )
button.
Refer to the instructions and then repeat
the measurement.
1. Check the batteries and, if necessary, fit
4 new batteries.
2. Reinsert the batteries with the +/- poles
the right way round.
3. Clean the battery contacts with a dry
cloth.
Fit new batteries.
Check that the air tube is properly
connected to the monitor. Push the tube
connector firmly into the socket.
Contact your Omron retailer or distributor.
