Labtron V223 Mobile Adjustable Aneroid Sphygmomanometer 3
aneroid
sphygmomanometer
lowerbracket
M4screw
basket
spring
largewasher
M8screwand
smallwasher
V223 Mobile Adjustable
Aneroid Sphygmomanometer
upperbracket
M6screw
andwasher
upperpole
height
adjustment
knob
lowerpole
base
polebase
caster
ASSEMBLY
Refer to the picture above to assemble the Mobile Height-
Adjustable Aneroid Sphygmomanometer.
1. Assemble casters and base.
2. Insert pole base into base.
