3-5
Cisco AVS 3180 Management Station Hardware Installation Guide
78-17292-01
Chapter 3 Installing the AVS 3180
Installing Your AVS 3180
Figure 3-2 Removing the Inner Server Rail
3.
Using a screwdriver (1), gently press the button labelled “Push” and move the middle section of the
outer telescopic rail to its end position, as shown in Figure 3-3.
Figure 3-3 Telescoping the Rail
119961
2
1
99522
1
