Getting Started
Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775
ViewSonic 13 N2690w
Side View of the Product
Item
Description
A
Headphone Jack
Connect to your headphones. By connecting the
headphones, you can listen to the sound from the TV
on headphones.
＊If you connect the headphones, the TV speakers will
be muted
AV connection
Connect the composite video and audio input jacks to the corresponding output jacks
of your A/V device.
--- VIDEO: Composite Video input [6]
--- AUDIO: AV/ S-Video signal Audio input [6]
S-Video connection
Connect the S-Video and audio input jacks to the corresponding output jacks of your
VCR or other video device that has S-Video. S-Video provides better picture quality
than composite video connection. If both are connected, S-Video signal has priority.
--- VIDEO: S-Video input [6]
--- AUDIO: AV/ S-Video signal Audio input [6]
Component (YPbPr) connection
YPbPr provides better picture quality than the S-Video or the AV connection.
＊For YPbPr connection, connect the component video (YPbPr) and audio jacks
to the corresponding
output jacks of your A/V device.
--- VIDEO: YPbPr signal input [3]
--- AUDIO: YPbPr signal audio input [3]
