topology type of design, conditioned power is provided continuously to its connected devices. Unlike standby
UPS’s, its on-line structure always regulates and filters output power when commercial power is present.
During line power failure, the unit employs its internal maintenance-free battery to supply back-up power
without any transfer time. In the event of an overload or inverter failure, the UPS will transfer to bypass
mode as an alternate source. The UPS can transfer back to the inverter mode automatically after the
overload condition has been cleared. All transfers noted above occur with zero transfer time that can ensure
your equipment’s continuous operation.
1.3 PRODUCT SPECIFICATIONS
ELECTRICAL & MECHANICAL SPECIFICATIONS
MODEL
Output
Current
RATING Hz
Input
Voltage
Output Voltage
SG0603 28.8/27.3/26/25A
6KVA
4.2KW
50/60
Hz
170-276
VAC 208/220/230/240V
SG0604
50,25/25,28.8
25/28.8,25,25/25A
6KVA
4.2KW
50/60
Hz
170-276
VAC
120, 120/120, 208,
120/208,240,120/240V
SG1003 48.1/45.5/43.5/41.7A
10KVA
7KW
50/60
Hz
170-276
VAC
208/220/230/240V
SG1004
83.3,41.7/41.7,48
41.7/48,41.7,41.7/41.7A
10KVA
7KW
50/60
Hz
170-276
VAC
120, 120/120, 208,
120/208,240,120/240V
INPUT
Voltage: As listed
Phase: Single phase with ground
Frequency: 50/60Hz +/- 5%, auto selection
Power factor: >/= 0.97
OUTPUT
Output voltage regulation: +/-3%
Power factor: 0.7 lag to unity
Frequency regulation: +/-5%, phase lock to input under normal conditions, +/-0.5% of nominal
frequency, under normal operation or battery mode.
Distortion: +/-3.0% THD at full linear load, +/-7% THD at full non-linear load
Overload Capacity: >130% +/-10% for 200 ms, 105% for 10 second
Load Crest Ratio: 3:1 maximum
OPERATING ENVIRONMENT
Ambient temperature: 10 to 40 degrees Centigrade
Operation humidity: 20% to 90%, non-condensing
Altitude: less than 1500M above sea level
Storage temperature: -15 to 40º C
MODEL MEASUREMENTS WEIGHT
SG0603
31.5 x 10.25 x 23.25
in. 200.6(215.5)lb.
SG0604
31.5 x 10.25 x 23.25
in. 296(311.6)lb.
SG1003 38 x 13.5 x 26.5 in. 396.8(429.4)lb.
SG1004 38 x 13.5 x 26.5 in. 519.6(552.2)lb.
