10 – Display and Configuration (continued)
10-5-1 Bypass Setup (continued)
From the “FREQUENCY RANGE” screen, use the scroll buttons •
( , ) to select a bypass frequency range and press the enter
button ( ) to confirm the setting.
Press “ESC” to return to the “UPS SETUP” menu.
10-5-2 Output Setup
Use “ ” or ” ” to select “OUTPUT SETUP”, then press ” ” to
confirm.
3
All parameters in this segment can only be changed when UPS is in “Bypass Mode”.
Enter the UPS system setup menu. Use the scroll buttons (• , )
to move the cursor to “OUTPUT SETUP”, then press the enter
button ( ).
1
