10 – Specifications

11 – Storage and Service

Input

Voltage Range Upto160-280/277-485VAC(3Ø,4-Wire+Ground,Wye)

(160-176/277-305VACatLoad<75%)

Frequency Range 45to65Hz

Power Factor Upto0.99at100%LinearLoad

Output

Voltage Range User-Selectable200/220/230/240VAC(1Ø,2-Wire+Ground)

Voltage Adjustment ±0%;±1%;±2%;±3%

Voltage Regulation ±2%

Capacity 10kVA/7kW

Rated Power Factor 0.8 Lagging

WaveForm PureSineWave,THD<3%

Frequency Stability ±0.2%(Free-Running)

Frequency Regulation ±1%;±3%

Transfer Time to Battery 0 ms

Crest Factor 3:1Acceptable

Efficiency(ACtoAC,NormalMode) Upto91%

Efficiency(ACtoAC,EconomyMode) Upto93%

Estimated Full Load Runtime 5 minutes

EstimatedHalfLoadRuntime 14 minutes

Physical

Dimensions(HxWxD) 135x440x680mm(PowerModule)

Input/OutputConnection Hardwire

UnitWeight 28kg(PowerModule)

Storage

First turn the UPS system’s output and utility input breaker OFF, then disconnect the UPS system’s input from the AC utility power source.

Next,disconnectallequipment.TheUPSsystemmustbestoredinaclean,secureenvironmentwithatemperaturelessthan40°Canda

relativehumiditylessthan90%(non-condensing).Note: If the UPS system remains off for an extended period of time, it should be turned

on periodically to allow the batteries to recharge. The UPS system should be turned on and the batteries should be recharged at least one

uninterrupted 12-hour period every three months in moderate-temperature environments (-15° to 30° C), or every two months in high-

temperature environments (30° to 40° C). Failure to recharge the batteries periodically may cause irreversible battery damage.

Service

The UPS system is covered by the limited warranty described in this manual. Extended and on-site warranty options are also available. For more

information,callTrippLiteCustomerServiceat+1.773.869.1234.IfreturningtheUPSsystemtoTrippLite,carefullypacktheUPSsystemusing

theoriginalpackingmaterialthatcamewiththeunit.Enclosealetterdescribingthesymptomsoftheproblem.IftheUPSsystemiswithinthe

warranty period, enclose a copy of the sales receipt.
