MUTE/TEST Button:
Silence the UPS On-Battery Alarm: Pressandholdthisbuttonto
silencetheUPSon-batteryalarm,aseriesofshortbeepsfollowed
byabriefpausethatisactivatedwhentheUPSisprovidingAC
powerfrombattery.Note:Whenthebatteryisnearlydepleted,the
lowbatteryalarm—acontinuousbeepthatcannotbesilenced—
willwarntoshutdownconnectedequipmentimmediately.
Run a Self-Test: Torunaself-test,leaveconnectedequipmenton.
WiththeUPSpluggedinandON,pressandholdthebuttonuntil
theUPSbeeps(about2seconds)thenreleaseit.
Self-Test Results: AllLEDswillbelitandtheUPSwillemitseveral
shortbeepsasitmomentarilyswitchestobatterytotestcharge
andloadcapacity.Thetestwilllastupto10seconds.Ifthe
inverterisoverloaded,the“ ”LEDwillstaylitandtheUPSwill
continuetobeepafterthetest;ifthishappens,removesomeof
theloadfromthe“UPS/Surge”outletsandruntheself-testagain.
Ifthebatteriesareweak,the“ ”LEDwillstaylitandtheUPSwill
continuetobeepafterthetest.Ifthishappens,lettheUPScharge
itsbatteriesfor12hoursandrepeatthetest.Ifthecondition
persists,contactTrippLiteforservice.CAUTION:Donotunplugthe
UPStotestitsbatteries.Thiswillremovesafeelectricalgrounding
andmayintroduceadamagingsurgeintonetworkconnections.
Basic Operation continued
AllIndicatorLightdescriptionsapplywhentheUPSispluggedintoanACoutletand
turned on.
LINE POWER: ThisgreenlightwillilluminatewhenevertheUPSisON
and receiving normal AC line power.
Indicator Lights
BATTERY POWER:ThisyellowlightwillilluminatewhentheUPSis
providingequipmentwithbatterypower.
REPLACE BATTERY: This red light will illuminate continuously after the
UPSrunsaself-testtoindicatethatthebatteryisweak.Ifitremainslit
afterallowingtheUPStochargefortwelvehoursandrunningasecond
self-test,contactTrippLiteforservice.
OVERLOAD: This red light will illuminate continuously to indicate that
theUPSisoverloadedwhentheUPSisprovidingpowerfrombatteryor
aftertheUPSrunsaself-test.Ifitlightsup,immediatelyremovesome
oftheequipmentconnectedtothe“UPS/Surge”outletsandrunaself-
test.LargeoverloadsmaycausetheUPStoshutdown.
