Mode Resolution
A B C D E fh fv clock G H I J K
(pixels) (pixels) (pixels) (pixels) (pixels)
(kHz) (Hz) (MHz)
(Lines) (Lines) (Lines) (Lines) (Lines)
*
SXGA1152x864 75Hz
1152 x 864 256 1152 64 128 1600 67.500 75.000 108.000 32 864 1 3 900
*
SXGA1280x960 60Hz
1280 x 960 312 1280 96 112 1800 60.000 60.000 108.000 36 960 1 3 1000
*
SXGA1280x960 85Hz
1280 x 960 224 1280 64 160 1728 85.938 85.002 148.500 47 960 1 3 1011
*
SXGA1280x1024 60Hz
1280 x 1024 248 1280 48 112 1688 63.981 60.020 108.000 38 1024 1 3 1066
*
SXGA1280x1024 75Hz
1280 x 1024 248 1280 16 144 1688 79.976 75.025 135.000 38 1024 1 3 1066
*
SXGA1280x1024 85Hz
1280 x 1024 224 1280 64 160 1728 91.146 85.024 157.500 44 1024 1 3 1072
*UXGA60 1600 x 1200 304 1600 64 192 2160 75.000 60.000 162.000 46 1200 1 3 1250
*UXGA65 1600 x 1200 304 1600 64 192 2160 81.250 65.000 175.500 46 1200 1 3 1250
*UXGA70 1600 x 1200 304 1600 64 192 2160 87.500 70.000 189.000 46 1200 1 3 1250
*UXGA75 1600 x 1200 304 1600 64 192 2160 93.750 75.000 202.500 46 1200 1 3 1250
Mode fh(kHz) fv(Hz) fsc(MHz)
NTSC 15.73 60 3.58
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
Mode fh(kHz) fv(Hz)
525i 15.73 59.94
525p 31.47 59.94
625i 15.63 50.00
750p 45.00 60.00
1125i 33.75 60.00
Applicable signal (continued)
Timing chart (Continued)
• Signal sources marked "*" are displayed in compressed format, so some of their data may be missing or their picture quality may be degraded.
• With analog RGB inputs, if the signal source’s dot clock frequency exceeds 165 MHz, not all of the pixel signals can be sampled.
• For digital RGB inputs, the projector is not compatible with signal sources whose dot clock frequency exceeds 162 MHz.
The compatible Video and S-Video signal The compatible components video signal (Y/PB/PR)
Notes
