When using a non-PoE hub
Use a PoE power injector to connect between the Network Camera and a non-PoE
switch.
POWER
COLLI
SION
LINK
RECEIVE
PARTITION
1
2
3
4
5
When using a PoE switch
The Network Camera is PoE-compliant, allowing transmission of power and data
to both run in a single Ethernet cable. See the following illustration to connect the
Network Camera to a PoE switch via Ethernet cable.
POWER
COLLISION
LINK
RECEIVE
PARTITIO
N
1
2
3
4
5
PoE hub
(not supplied)
Non-PoE switch
(not supplied)
PoE power injector
(not supplied)
Power over Ethernet (PoE)
In this instance, have no use for
AC adapter.
In this instance, have no use for
AC adapter.
