TASCAM RC-601MKII 13
MENU OPERATIONS
Various settings on the CD-601MKII can be made using
the menu. Menu operations can be performed on either of
the CD-601MKII and RC-601MKII. Although their settings
and indications are exactly the same, the keys used for
operation differ slightly.
All operations including menu operations on the
CD-601MKII are not possible while menu operations are
being executed on the RC-601MKII. Likewise, all operations
including menu operations on the RC-601MKII are not
possible while menu operations are being executed on the
CD-601MKII.
Menu Configuration
The menu contains the following items. The items and details of each item are exactly the same as those in the menus on the
CD-601MKII.
Menu
No.
Item Display Details Display Description Reference Item
01 A_CUE Auto cue level Auto cue level setting “Setting the Auto Cue Level” (p. 17)
02 ONLINE Online play output Setting the terminals for online
output
“Setting the Terminals for Online Output” (p. 24)
03 MONI Monitor output Setting the terminals for monitor
output
“Setting the Terminals for Monitor Output” (p. 24)
04 CLOCK Clock source Operation clock setting “Referencing to an External Clock Source” (p. 25)
05 PROG Program setting Program setting “Program Playback” (p. 16)
06 INCR_P Incremental play Incremental play ON/OFF “Incremental Play Function” (p. 18)
07 TIMER Timer play Timer play ON/OFF “Timer Play Function” (p. 27)
08 OUTPUT Output stereo mono Output stereo/monaural setting “Setting Stereo/Monaural” (p. 24)
09 OUT_L Output level Output level setting “Setting the Output Level” (p. 24)
10 F_SAFE Fail safe Failsafe function ON/OFF during
online playback/READY
“Failsafe Function” (p. 25)
11 EOM End of message time End of track warning display setting “Displaying the End of Track Warning” (p. 26)
12(*) E_CHK End check time End check time setting “Checking the Ending of Tracks” (p. 26)
13(*) BANK Memory BANK select Memory back selection “Saving Disc Information” (p. 23)
14(**) F_STAR Fader start polarity Setting fader start polarity CD-601MKII Owner’s Manual
15(**) F_STOP Fader stop state Setting the state of the CD player
at a fader stop
CD-601MKII Owner’s Manual
16 CUE_UP Auto CUE up state Setting the CD player standby
mode during an auto cue or an
auto ready
“Auto Ready Function” (p. 17)
17(*) RMT Remote control CD player operation enable/disable
setting when remote control (*)
RC-601MKII is used
“Preparations” (p. 8)
18 FRAME Frame display Setting the frame display of the
time display area of the display
window
“Clearing the Frame Display” (p. 27)
19 TIME Time display Setting the time display switching
pattern
“Switching the Time Display” (p. 26)
20 CUESET Cue point set Cue point setting “Auto-registering Cue Points” (p. 9)
21 A_CLR Memory ALL clear Memory all clear “Clearing Menu Settings” (p. 15)
22 USER User setting Calling up user banks to save
settings to
“Saving Menu Settings” (p. 15)
23(**) RS232C Com PORT baud rate RS-232C baud rate setting CD-601MKII Owner’s Manual
(none) xxxxH Motor addition time
display
Motor total drive time display “Viewing the Total Motor Time” (p. 27)
* Menu items followed by (*) in the above table are valid when the Remote Control Unit RC-601MKII is connected.
* Menu items followed by (**) in the above table are external control-related items. For details on these items, refer to the
CD-601MKII Owner’s Manual.
