Control Font Usage
All models include the Control device font. This font is used to provide for control within the span of a
single document. For example, if your document wishes to print a logo in the middle, this can be done via
the control font.
Usage of the Control font must be done as follows:
1. Choose the control font from your editor’s font menu.
2. Enter the characters that map to the desired printer actions. This character to function map is as
follows:
Character Function Control Code Translation
A Open cash drawer 1 for 50mSec
\x1b\x07\x05\x05\x07
B Open cash drawer 1 for 100mSec
\x1b\x07\x0a\x0a\x07
C Open cash drawer 1 for 150mSec
\x1b\x07\x0f\x0f\x07
D Open cash drawer 1 for 200mSec
\x1b\x07\x14\x14\x07
E Open cash drawer 1 for 250mSec
\x1b\x07\x19\x19\x07
d Open cash drawer 2 for 200mSec
\x1a
6 LF
\x0a
7 CR
\x0d
F Full Cut
\x1bd0
P Partial Cut
\x1bd1
G Print NV Logo No. 1
\x0a\x1b\x1cp\x01\x00
H Print NV Logo No. 2
\x0a\x1b\x1cp\x02\x00
I Print NV Logo No. 3
\x0a\x1b\x1cp\x03\x00
J Print NV Logo No. 4
\x0a\x1b\x1cp\x04\x00
K Print NV Logo No. 5
\x0a\x1b\x1cp\x05\x00
Q Print NV Logo No. 1 – Double Wide
\x0a\x1b\x1cp\x01\x01
R Print NV Logo No. 2 – Double Wide
\x0a\x1b\x1cp\x02\x01
S Print NV Logo No. 3 – Double Wide
\x0a\x1b\x1cp\x03\x01
T Print NV Logo No. 4 – Double Wide
\x0a\x1b\x1cp\x04\x01
U Print NV Logo No. 5 – Double Wide
\x0a\x1b\x1cp\x05\x01
V Print NV Logo No. 1 – Tall
\x0a\x1b\x1cp\x01\x02
W Print NV Logo No. 2 – Tall
\x0a\x1b\x1cp\x02\x02
X Print NV Logo No. 3 – Tall
\x0a\x1b\x1cp\x03\x02
Y Print NV Logo No. 4 – Tall
\x0a\x1b\x1cp\x04\x02
Z Print NV Logo No. 5 – Tall
\x0a\x1b\x1cp\x05\x02
[ Print NV Logo No. 1 – Double Wide / High
\x0a\x1b\x1cp\x01\x03
] Print NV Logo No. 2 – Double Wide / High
\x0a\x1b\x1cp\x02\x03
^ Print NV Logo No. 3 – Double Wide / High
\x0a\x1b\x1cp\x03\x03
_ Print NV Logo No. 4 – Double Wide / High
\x0a\x1b\x1cp\x04\x03
‘ Print NV Logo No. 5 – Double Wide / High
\x0a\x1b\x1cp\x05\x03
a Set Left Alignment
\x1b\x1da\x00
b Set Center Alignment
\x1b\x1da\x01
c Set Right Alignment
\x1b\x1da\x02
e Set 3mm line feed spacing
\x1b0
f Set 4mm line feed spacing
\x1bz1
g Select USA international character set
\x1bR\x00
h Select France international character set
\x1bR\x01
i Select Germany international character set
\x1bR\x02
j Select England international character set
\x1bR\x03
k Select Denmark I international character set
\x1bR\x04
l Select Sweden international character set
\x1bR\x05
m Select Italy international character set
\x1bR\x06
n Select Spain I international character set
\x1bR\x07
o Select Japan international character set
\x1bR\x08
p Select Denmark II international character set
\x1bR\x09
q Select Spain II international character set
\x1bR\x0a
r Select Latin America international character set
\x1bR\x0b
