Setting up the hardwareNetwork Media Receiver
Connection possibilities
Connecting the Network Media Receiver to a TV
Use the supplied audio/video connection cable to connect the Network Media Receiver and your TV. Connect the cable by matching
the connector colours to the jack colours on the TV’s audio/video jacks.
Optional equipment and cables may be required to connect the Network Media Receiver, TV, VCR and VAIO computer, depending
on your connection environment.
The arrows indicate the signal direction.
1 S-video cable (sold separately)
2 Audio/video connection cable (supplied)
S-video
L
R
Video Input
1
Video
Audio
