Transmission, Belt, & Carrier Group — Hydro Models
17
TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693080 Regent 14HP Hydro
1693082 Regent 14HP Hydro (Ex)
1693088 Regent 16HP Hydro
1693090 Regent 16HP Hydro (Ex)
1693094 514H, 14HP Hydro
1693098 516H, 16HP Hydro
1693102 2514H, 14HP Hydro
1693104 2516H, 16HP Hydro
1693325 Regent 14HP Hydro
1693329 Regent 16HP Hydro
1693333 Regent 14HP Hydro (Ex)
1693337 Regent 16HP Hydro (Ex)
1693341 514H, 14HP Hydro
1693343 516H, 16HP Hydro
1693347 2514H, 14HP Hydro
1693349 2516H, 16HP Hydro
1 1931277 4 NUT, Hex Flange Whiz-Lock, 5/16-18
2 1928698 1 JAM NUT, Top Lock, 5/16-18
3 1717427 1 ANCHOR, Torsion Bar, L.H.
4 1960586 4 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 2-1/2
5 960584 1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3-1/2
6 960583 1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3
7 960551 2 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 2-1/2
8 1960585 1 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 1-1/4
9 1927557 1 NUT, Hex, Flange Whiz Lock, 5/16-18
10 1717424 1 TORSION BAR
11 1717428 1 ANCHOR, Torsion Bar, R.H.
12 1717194 1 TRANSMISSION ASSEMBLY, Tuff Torq K-56
13 1930810 3 CAPSCREW, Taptite Hex Washer Hd, 1/4-20 x 1-1/2
14 1717425 1 FAN
15 1708269 2 SET SCREW, Brass Tipped
16 1707932 1 PULLEY ASSEMBLY
17 158399 1 RETAINING RING
18 1921333 1 CAPSCREW, Hex Hd, 5/16-18 x 1
19 1930644 2 NUT, Flange, 1/2-13, 2-Way Lock
20 1717286 1 SPACER
21 1918431 3 WASHER, 1/2
22 1920328 2 CAPSCREW, Hex Hd, 1/2-13 x 1-1/2
23 1709235 1 BUSHING
24 1717292 1 GUIDE, Belt
25 1919326 2 WASHER, 5/16
26 1664847 1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
27 1917372 1 NUT, Hex, Full, 5/16-18
28 1917356 1 LOCKWASHER, 5/16
29 1717397 1 BELT, Drive
30 1717442 1 ROD, Transmission Release
31 1918447 1 COTTER PIN
32 1717189 1 CARRIER, Transmission, Hydro
