Using the TV’s Features
22 Chapter 3
The main PIP buttons (PIP, CH
CTRL and SWAP) are at the
bottom of the remote control.
The PIP (Picture-In-Picture) Feature
The PIP (Picture-In-Picture) feature lets you display a second, smaller picture on top of the
main picture.
How To Use PIP
While you can use PIP in different ways, this basic PIP scenario should get you
started.
1. The TV must be on. Tune to the channel you want to watch.
2. Press the PIP button on the remote (the PIP picture appears with the same
picture in it as the main picture).
3. To change the picture in the PIP window, press the CH CTRL button on the
remote control and then press the channel up or down buttons.
4. To change the channel in the main picure, press CH CTRL again and then
press the channel up or down button on the remote control.
.
PIP Buttons: General Explanation
The buttons on the remote control that you’ll use for the PIP feature are
explained below:
PIP Press the PIP button to make the PIP window appear on the screen. Press
PIP again to remove the window.
Right arrow button Moves the PIP window to different areas of the screen.
Press and hold or just press.
CH CTRL (channel control) Lets you switch channel control between the PIP
window and the main picture. To determine whether the remote control is the
PIP picture or the main picture, look at the TV screen: the channel with the
white circle next to it is the one you are controlling. Press CH CTRL to change
which picture you’re controlling.
SWAP Switches, or “swaps,” where the two pictures appear on the TV screen.
The smaller PIP picture swaps to the main screen and the main picture goes to
the little PIP window.
Note: Swap won’t work if the remote is in the wrong mode. For example,
once you turn on the VCR with the VCR1 button, you can’t SWAP the
pictures until you put the remote in TV mode. Just press the TV button.
123
456
789
0
ON•OFF
TVVCR1
DVD
MUTE SKIP
GO BACKSOUND
GUIDE INFO
MENU CLEAR
INPUT
REVERSE PLAY FORWARD
RECORD
PIP SWAP CH CTRL RESET
STOP PAUSE
ANTENNA
AUX
SAT•CABLE
OK
CH
+
CH
VOL
VOL
VCR2
