Figure 4-7 Per port static screen
#Notice:
The TX/RX packets counted with error might because:
z Packet with a bad FCS.
z Packets were less than 64 bytes or greater than 1522 bytes.
z Packets were dropped due to lack of resources.
4.4.2.3 Show vlan [n]
Display one specific VLAN group status of GSW-2416SF. GSW-2416SF supports up to 24-port based VLAN Groups and
the correct usage is shown as below:
Show vlan to view all VLAN Group and port member assigned status.
Show vlan [n] n=1-24, to view one specific VLAN Group and port member assigned status.
[n] is the VLAN Group ID.
The specific VLAN Group status screen in Figure 4-8 appears.
Figure 4-8 VLAN group status screen
EM-GSW2416SFv1 - 17 -
